ASUS RS720-E12-RS8G/3.2KW/8N/G - 90SF03T1-M000H0
CPU model: Intel Xeon 6 Processor Scalable Family U size: 2 U Number of CPU slots: 2 PCI-E generation: PCIe 5.0 Number of PCI-E: 10 Number of DIMM slots: 32 Number of drive bays: 8
We also offer six months of free collocation in our TIER III data center.
Components are not the end — ask us for a custom server configuration. We will design the server, assemble it, expertly set it up, and provide extended or NBD warranty.
| Product code | 202.180382 |
|---|---|
| Part number | 90SF03T1-M000H0 |
| Manufacturer | ASUS |
| Availability | Not in stock |
| Warranty | 36 months |
| Weight | 20 kg |
| The price includes all legal fees | |
Detailed information
Your trusted IT solution partner
ASUS is a global technology leader with over 5,000 R&D professionals and 2,200 service centers covering 98 countries over the world. With over 25 years of experience of building high-quality servers and software platforms, the core value of ASUS servers are to deliver performance, green computing and management to optimize the right mix of solutions for customer success. We believe our ASUS DNA in innovation will continue bringing more innovation for future and tomorrow.
Superior Performance
Continues to dominate benchmarks with ever-growing world records
Green Computing
Ranks as top power-efficient servers, delivering lower TCO in data centers
Improves IT management
Improves IT management, efficiency and system integration
ASUS Control Center
ASUS Control Center (ACC) is an enterprise-grade centralized management tool for servers and client devices. It is tailored for efficient IT management, including both hardware- and software-inventory management, and the remote dispatch of both software and firmware updates. It also allows for simple remote device configurations and health checks, plus rapid deployment of latest security policies and patches. In short, ACC is a one-stop portal for IT management, and has been embraced by industries and businesses globally to minimize administration and maximize uptime
Massive Performance
Transform your data center TCO with the high-density server powered by Intel Xeon 6 Processor Scalable Family Processor. With an innovative design that fits four nodes in a 2 U chassis,90SF03T1-M000H0 accommodates 2 CPUs, PCIe 5.0 to satisfy the increasing demands for efficiency, density and TCO-optimization for data centers, web servers, virtualization and hyperscale environments.
High CPU Performance
2 sockets
PCIe Expansion
10 slots
DDR memory
32 DIMM
Drives
8 bays
- Processor
CPU Intel Xeon 6 Processor Scalable Family Socket LGA4710 TDP 350 - System memory
Memory maximum Capacity 4TB Memory Slots 32 Memory Type DDR5 6400MHz (1DPC)/5200(2DPC) - Expansion slots
PCIe Total 10 expansion slots
6 x PCIE Gen5 x8 or 3 x PCIE Gen5 x16 (FHFL)
2 x PCIE Gen5 x16 (FHHL)OCP 2 x OCP3.0 Gen5 x16 (SFF) - Storage
Drive Bays 8 x 2.5" hot-swap drive bays Other Support 8x NVMe/SATA*/SAS*
*HBA/ RAID card is required to support SATA/SAS hard drives EDIT- Input/output
Front 2 x USB 3.2 Gen1 ports Rear 2 x USB 3.2 Gen1 ports
1 x Mini-DP port
1 x RJ-45 Management LAN port
1 x Debug port
- Switch/LED
Indicators Front Switch/LED:
1 x Power Switch w/ LED
1 x Reset Switch
1 x Location Switch w/ LED
1 x HDD Access LED
1 x Message LED
Rear Switch/LED:
1 x Power Switch w/ LED
1 x Location Switch w/LED
1 x Message LED- Management
Software On-Board ASMB12-iKVM for KVM-over-IP
ASUS Control Center Enterprise (Classic C)(Optional)- Dimensions
Form Factor 2U Rack Height 88mm Width 449mm Depth 830mm Weight 21.34kg - Power supply
Certification Titanium Power 3200W QTY 2
Parameters
| Size in U | 2 |
|---|---|
| Depth (mm) | 830 |
| CPU manufacturer | Intel |
| Socket | 3647 |
| HDD disks | |
| 2.5" Drive bays | |
| 3.5" Drive bays | |
| NVMe slots | 8 |
| Total amount of PCIe | 8 |
| OCP/AIOM | 1 |
| Power (W) | |
| Efficiency certification | Titanium |
